Sun drying CORSAIR American pirate ship: spec-m2 small chassis + cs450m power installed
This story calls for a solid-state drive. I want to set up a computer. What is the difference? Recently handed a ssd, pc experience a lot of increase can not help but itchy heart, just two manufacturers of new generation graphics sales, accompanied by my more and more strenuous years of gtx650ti light machine card I want to retired, and it's Good comrades, low power graphics artifacts, 300w power supply, it's time to say goodbye. The initial idea is to change the power supply and graphics card, but as soon as you think of reinstalling your machine, you can better replace the big, broken, hot chicken chassis that has been abandoned for a long time. This motherboard is matx, just for a small chassis can be placed on the table. So in the various forums to explore the small chassis, looked for two days did not find it particularly desirable. There are roughly three types of small chassis specifically designed for matx. The first type is the common style of the silkworm, performance compression, graphics limit, fan limit, cooling system more general stuffy tank type, suitable for htpc. The second is the kind of TT s3, the long is the appearance of the big board chassis, shrinking in terms of capacity, both sideways and not sideways. Light tt itself out of several, such as Most of the positioning is an entry-level chassis. If you want to put the budget within 500, the distinguishing feature of this chassis is that the hard disk location has only 2 hard drives, and it does not meet my needs. The third type is the horizontal chassis, because the matx is smaller, so the horizontal chassis size is not particularly exaggerated. This chassis is a little upscale 250d with a pirate ship There is also the same factory air 240 A few of the mid-range tt core series The low-grade also has the first horse's rice cube and carbon cube. This chassis can meet everyone's needs in terms of performance. The location of the hard disk, the limit of the graphics card are also OK, and the cooling is also good. However, most of them are too wide in terms of size. My table cannot be put down. Just when I was hesitant to prepare for teeth 250d, suddenly found the spec-m2 chassis is very popular, when the dog East evaluation of only seven, there are two stocks, most of the online search found only Evaluation of hardware portals is not seen. From the point of view of parameters, the capacity of the 22.5 + 23.5 + optical drive (which can change the hard disk position by itself) is very good, and the air path of the chassis 5 fan is also very good, and the thermal compatibility is also very strong. Although I am not a light control, I have a large side through the appearance. not bad. In terms of size, the width of the mid-turret chassis does not change much from that of the large-sized chassis. Power supply placement and board size restrictions make this chassis really high in length and height. The length of the iPhone 6 plus 2 cm, the side area is about the size of a 25-inch display. Just stand on the cs450m power, with 1060 problem is not large, all aspects are also good, so could not help but waved a wave of hands The logistics of Dog East is still awesome. It will be delivered in the evening in the afternoon. In the evening, the interior lighting is not good, but not the sister's photo too lazy to p map dimming, everyone will see The box diagram has been uploaded several times as http error. Everyone can make up for it by themselves. Anyway, it is cardboard plus outline of the shape of the chassis. The interior of the chassis package is secured with two foams. Dog East's logistics is still good, basically no bumps. The manual that comes with it, ah, is the picture on the outer packaging. Everybody can skip the clear content of everybody's brain. The appearance of the chassis, the material is quite thick, workmanship feels finer The internal structure, kraft paper is a chassis attachment, which is equipped with a variety of screws, as well as two pairs of 3.5-inch hard drive bay without screws. Go backline design, the front panel line has already helped you in advance. The chassis comes with a fan and other internal details. This fan is only equipped with the motherboard's 3pin port connector. Prepare the new fan and move it to the back. Several screw positions next to the fan are used to install ssd and are directly attached to the inside of the chassis. Outlet design at the top and back of the chassis. The hole is large, the feeling is forcing you to put fans on these ports This is an internal attachment. There are several tie straps. The actual measurement plus the cable tie that comes with the power supply cannot be used up. Open the chassis and start to power on. The packaging is still very solid and slightly bumped. After opening it is like this, there is no shockproof processing also has to lose is the dog logistics This box should be opened like this. . . I haven’t seen it for a long time and forced it to open Power main parts, work meticulous, feel good, holding a lot of weight. Main wire, outside net bag This power supply also comes with a strap The module line has four, 6+2 graphics card power supply, two 15pin hard disk power supply, each has two ports, just two power supply to the hard disk area. A large 4pin round mouth power supply with three ports on top. Have to spit about the chassis and this power collocation. The location of the mechanical hard disk is fixed, and there is no way to adjust the mounting orientation of the mechanical hard disk below. Otherwise, the plug cannot be inserted, resulting in very few power module selections for the two mechanical hard disks. The mechanical hard disk power supply module for this power supply is very small. The line is bent, and the direction of the bend is exactly the only thing that can only go from bottom to top. In the end, in order to supply the two mechanical hard disks, my module line is bent out of a hard clip in the hard disk area. The shape just put two sata extension cords ready to save my power cord. Buy this chassis must remember that the module line must be straight This is the hard drive bay. Insert it on the hard drive and go inside. It feels quite stable. After installing the machine, anyway, we will add a fan to change the graphics card. Turned on, once lighted and watched the light felt like it was time for a glowing pollution. The side-through acrylic sheet has its own color, which will filter out some of the light intensity. Use feelings: The overall relatively quiet, probably because my demand is not high, cooling duct can also, but there is a more obvious shortcomings, mechanical hard disk vibration feeling more obvious, I feel need to add a cushioning device.
